EN801M is a camera processor for security camera system with MIPI-CSI2 receiver up to 1080p60. It supports various WDR(HDR) methods such as ‘Line by Line’, PWL and LFM based on an adaptive tone-mapping. It also features AI Digital Noise Reduction, Adaptive Contrast Enhancer equipped with AE/AF/AWB control to achieve high quality image. It has SDI transceiver that targets SDI long distance with EX-SDI technology and a MIPI-CSI2 TX.


Input : MIPI CSI-2 DPHY 1/2/4 lane Max 1.5Gbps (RAW10,RAW12)
Output : EX-SDI, MIPI CSI-2 DPHY 2/4 lane (Max. 1.2Gbps) (YUV8/YUV10)
Package : 56 QFN (6x6)
Resolution : Max. 2M (Full HD)
Frame rate : Max. 2M 60p
Feature : WDR(Sensor dependent), LFM(Sensor dependent), AI-DNR, Up scaler(Up to 4~5M), AE, AWB.. ETC.
