The EN781/781F camera processor for security camera system. The main features include Wide Dynamic Range (WDR), Adaptive Contrast Enhancer, 3D Noise Reduction, auto AE/AF/AWB control, digital zoom and built-in EX-SDI. This is an SDI transceiver that targets SDI long distance with EX-SDI technology and has a high performance DAC, which includes an analog HD encoder, so you can transmit all kinds of analog HD without dedicated chipsets.


Input : MIPI CSI-2 DPHY 4/8 lane Max 1.5Gbps (RAW12), sub-LVDS 2/4/6/8 lane Max. 600Mbps
Output : EX-SDI, HD Analog, BT1120/BT656(Parallel)
Package : 144 FBGA (10x10)
Resolution : Max. 4K (Ultra HD)*
Frame rate : Max. 2M 60p, Max. 4M 30p (Single)
Feature : WDR, 3D-DNR, D-Zoom, FRC, AE, AWB.. ETC.
* 자세한 내용은 4K Solution 페이지 참고
